LED Tail Lamp with Dynamic Indicator - 12/24V

L1830

Sold singly, 1x light per box

LED tail lamp with dynamic indicator 12/24V

Technical data
• Product dimensions: 283x100mm
• Cable: 500mm
• Working voltage: 12/24V
• Approvals, certificates:
ECE R3, R6, R7, R10, R23, R38
• Power consumption:
0,6W + 3,1W + 3,1W + 2,8W + 3,6W
• LED quantity: 64pcs
• Material of execution:
Housing: ABS
Lens: PMMA/PC
• Working temperature:
from -40°C to + 60°C

Functions
• Rear lamp LED
• For automotive use only
• The lamp has road approval ECE R3, R6, R7, R10, R23, R38 authorizing it to be used on public roads
• The lamp is intended for vehicles with 12/24V installation
• Reverse polarity protection

Mounting method
• Installation only in specialized workshops or professional service
• Lamps must be installed only in accordance with the UNECE regulations
Wire connection

Wiring:
Ground - Black
Position - Green
Indicator - Green/Brown
STOP - Red/Blue
Reverse - Green/Purple
Fog - Red
