Front Fog Light F210 - 6cm / 10Watt - Purelux
Compact and high-quality fog light with easy installation. Wide light image with safe demarcation in the vertical direction. Luminous flux 500 lm with a range of 89 m @1 lux. E-approved!
The Purelux F210 is a small and easy-to-install fog light of high quality. The Purelux F210 produces a narrow horizontal light image and has a limited width so that oncoming vehicles are not dazzled. The light image is very efficient and has a measured color temperature of 5800K, which makes your driving safer in poor weather conditions such as in rain, fog and darkness. The Purelux F210 has built-in protection against radio interference in accordance with the E-approval: ECE R10, but also meets all the criteria for the ECE-R149 classification for headlights approved as fog lights. The measured power is 10.7W with a luminous flux of 500 lumens and a range of 89 meters @1 lux.
The Purelux F210 is equipped with a shock-resistant aluminum frame that copes with vibrations from the roads in an optimal way and withstands hard knocks. In addition, the fog light is completely dust and waterproof according to protection class IP68/IP69K. The Purelux F210 has a mounting base in stainless steel, which reinforces the robust impression of the fog light. The wide operating voltage range (9-48V) makes it possible to install the fog light in both 12V and 24V systems. In the product selection, you can choose between buying one fog light, two fog lights or two fog lights with a suitable relay cable set.
Contents (1 pc)
Fog lights Purelux F210
Mounting foot
Mounting bolt
Deutsch DT2 contact coupling
Connection and installation instructions
Technical specification
Product: Fog light Purelux F210, 10 W
Area of use: As fog lights for vehicles
LED: 1 x 10W
Operating voltage: 9-48 V (DC)
Current consumption: 0.44A @ 24V
Estimated power: 10 W
Measured power: 10.7 W
Manufacturer's reported power: 10 W
Reported luminous flux: 1000 lm
Measured luminous flux: 500 lm
Measured range: 177 m @ 0.25 lux / 89 m @ 1 lux
Manufacturer's reported color temperature: 6000 K
Measured color temperature: 5800 K
Mounting: The fog light is mounted on a foot
Contact: DT2
Cable length: approx. 30 cm
Dimensions: 55 x 55 x 80 mm (width / height / depth)
Height with foot: 84 mm
Weight: 330 g
Protection class IP68 / IP69K
Approvals: CE, RoHS, ECE R10, R149
Warranty: 24 months
