Adjustable Programmable Relay / Timer Relay - 12V - Durite

Rated Voltage    12VDC
Operating Voltage    9-15VDC
Rated Current    10A / 15A
Max Allowable Overdrive Current    16VDC
Quiscent Current    5mA
Operating Current (relay on)    35mA
Max Switching Voltage    30VDC
Max Switching Power    240W
Operating Time Max    15ms
Release Time Max    10ms
Electrical Lifetime    100
Mechanical Lifetime    100
Reverse Polarity Protection    - 30VDC
IP rating    IP50
Vibration Resistance    10-50Hz 1.5mm
