On/Off HD Rocker Switch - Purelux

Convenient color-coded push-button switch with LED backlight for controlling auxiliary and work lights. On/off function. Current rating 30A, can be connected to power or excitation cable.

Purelux On/Off HD Rocker Switch is a handy on/off switch with LED light, e.g. for controlling auxiliary and work lights. With the switch, e.g. auxiliary lights can be installed to operate via a switch alone, when the switch is connected to the power or ground wire. The switch can also be connected to a relay wiring harness so that the auxiliary lights can be switched off, even if the vehicle's own high beams remain on. In such a situation, it is worth installing the switch on the wiring harness's excitation wire, so that the auxiliary light can be switched off from the switch and the vehicle's own high beams still remain in use (an excellent feature, e.g. when encountering oncoming traffic: the auxiliary lights can be switched off first and the high beams only a little later). However, with the above connection, the auxiliary lights will not come on if the car's own high beams are not on, i.e. they will operate at the same time as the car's own high beams, unless the auxiliary high beams are switched off separately from the switch.

The Purelux On/Off HD Rocker Switch is equipped with a handy LED backlight, making it easy to see even in a dark cockpit (the light is always on when the switch is in the ON position). The switch is available in three different color options: red, orange or white, so you can choose different colored switches to control different functions, for example, or just choose a color according to your preference.

Specifications
What: On/off switch Purelux HD Rocker Switch
Intended use: Control of auxiliary and work lights
Current rating: 30A
Color: White, amber or red
Switch has LED background light
