Driving Light / Lightbar Wiring Kit - 12V Deutsch DT Plugs - Available in 1,2,3 or 4 Outputs - Purelux

Purelux ProSerie relay wiring kit for installing Purelux additional lights, for example. Available with 1-4 DT2 connectors. Contains everything you need to connect additional lights! Suitable for 12V voltage.

1x output: Max. current endurance q80W, Wire thickness (from battery to relay) 16AWG / 1.18mm², Wire thickness (from relay to light) 16AWG / 1.18mm², Fuse 15A, Relay 40A 12V

2x outputs: Max. current endurance 360W, Wire thickness (from battery to relay) 14AWG / 1.86mm², Wire thickness (from relay to light) 16AWG / 1.18mm², Fuse 30A, Relay 40A 12V

3x outputs: Max. current endurance 400W, Wire thickness (from battery to relay) 12AWG / 2.94mm², Wire thickness (from relay to light) 16AWG / 1.18mm², Fuse 40A, Relay 60A 12V

4x outputs: Max. current endurance 480W, Wire thickness (from battery to relay) 12AWG / 2.94mm², Wire thickness (from relay to light) 16AWG / 1.18mm², Fuse 40A, Relay 60A 12V

The Purelux ProSerie relay wiring harness is a solution for easy and convenient installation of additional lights. This wiring harness contains everything you need to connect additional lights! Other relay wiring harnesses on the market often require additional connectors, etc. depending on the connection method, but this relay harness has everything you need. Depending on the model, the Purelux relay wiring harness can be used to install one to four high beam headlights. A wiring harness with one connector is sufficient for connecting a single light, but if you intend to add another (or more) light in parallel at some point, it is worth buying a wiring harness with at least two places, from which you can leave the extra connectors unused at first. The wiring harness is suitable for direct 12V power.

Specifications
What: Relay wiring kit Purelux Pro Serie 12V, DT
Purpose: Connecting additional car lights
Deutsch DT connectors for 1-4 high beam
Splash-proof fuse box
The length of the wires from the relay to the lights is approx. 2 meters
Suitable for both 12V voltage
Warranty: 12 months
