Epix20+ LED Lightbar - 20" 180Watt 11,800Lumen Powerboost Driving Beam - Amber or White DRL - LEDSON
The dynamic ignition of the position lights gives the bar an effective start-up. Everything you need and want in a LED bar, you’ll find with Epix+ Prime. We have maximized performance in an E-approved mode, with the option for powerboost when you choose to go ”off-road". Approved R65 strobe lights ensure your visibility when working on the road and keep you safe in all weather and times of the day. Self-developed smart mounts ensure easy installation almost anywhere on the vehicle, however you prefer.
Epix+ Prime is for you who want a futuristic experience
The design of the bar is uniquely developed by Ledson and is in harmony with today's most modern cars, taking your vehicle to the next level. Its dynamic position light turns on with a powerful movement that neatly guides the light from one side of the bar to the next before fully lighting up. The position light is integrated into the reflector, a completely unique feature that makes you stand out a little extra.
Powerboost: how much light do you want?
As if this wasn’t enough to look forward to, you also have the option to use powerboost. Simply tighten or loosen the screw in the back of the LED bar to switch between E-approved mode or ”off road” powerboost mode, for occasions when you need maximum brightness on the road ahead.
Driving Beam light pattern
Driving Beams reflectors are all computer generated and manufactured to provide a similar light image as combo. It mimics and enhances the car's existing headlight and light pattern.
What more is needed? NOTE: Also available as complete package here!
DT-relay: We strongly recommend using our cable harness with 1 x 4-pin DT (part no. 7801004). Ledson Connect provides a super easy connection while being interconnectable if there is a future desire to easily expand with additional lights or bars
Mounting on the vehicle: Can be mounted directly on the vehicle (drill in a suitable place) or a little smoother and nicer with the help of a number plate holder or pipe bracket. See our different accessories for mounting options. NOTE: specially developed holder is available for this LED bar here: Holder for Epix20+
Features and technical data:
Position light with unique dynamic ignition, integrated in the reflector
Selectable position light in xenon white or yellow/orange
Driving Beam light pattern (wide and oblong)
E-marked R112 (ref. no 50), R7, R10 (EMC rated) - Read more about UNECE regulations here
Range in E-approved mode: 458 m (1 lux),
Range in powerboost mode: 530 m (1 lux)
E-approved mode: 7 920 lumens (theoretical), 6 340 lumens (actual)
Powerboost mode: 15 500 lumens (theoretical), 11 800 lumens (actual)
Color temperature 5000K (Neutral White)
180 W (12 x 15 W LEDs)
Voltage: 9-36V
IP69K (water/dustproof)
Aluminum housing and polycarbonate lens
Side reflective optics
Pressure equalization membrane
Electronic heat management
DT connector (supplied)
Supplied:
Epix20+ Powerboost 20" LED bar
Bolts and screws to attach the bar to appropriate surface
Smart mounting details
Dimensions & weight (excl mounting):
Width: 510 mm
Height: 43 mm
Depth: 61 mm
Weight: 1,86 kg
